Hammer Crusher-ZOOMJO

Product Introduction

It has the characteristics of one-time forming, large crushing ratio, high production capacity and uniform product particle size. It is suitable for medium and fine crushing of limestone, coal or other brittle materials with medium hardness or below. Zhongjiao has a history of designing and manufacturing hammer crushers for more than 30 years. The products have advanced structure, reliable performance and low energy consumption. In addition, the hammer crushers produced by our company are reasonably priced and have formed a series of products, which are deeply welcomed by users at home and abroad.

The equipment is superior to its peers
and the performance is unmatched

Product Advantages

Efficient crushing of large-sized materials

It can directly crush large pieces of materials with a size of 600-1800mm to less than 25mm at one time, simplifying the crushing process and improving production efficiency.

Excellent performance characteristics

Widely applicable materials

Product Parameters

Model	Feed size(mm)	Discharge size (mm)	Processing capacity (m³/h)	Motor power (kw)	Weight(t)	Specifications (L×W×H)(mm)
PCΦ400×300	≤200	≤25	5-10	11	0.8	900×670×860
PCΦ600×400	≤250	≤30	10-22	22	2.26	1200×1050×1200
PCΦ800×600	≤250	≤35	18-40	55	4.8	1310×1180×1310
PCΦ1000×800	≤350	≤35	25-50	75	5.9	1600×1390×1575
PCΦ1000×1000	≤350	≤35	30-55	90	8	1800×1590×1775
PCΦ1200×1200	≤350	≤35	50-80	132-160	19.2	2060×1600×1890
PCΦ1400×1400	≤350	≤35	50-100	280	32	2365×1870×2220
PCΦ1600×1600	≤350	≤35	100-150	480	37.5	3050×2850×2800
