Product Introduction

The compound cone crusher adopts the best combination of crushing frequency and eccentricity, which makes it have higher crushing degree and higher crushing capacity compared with similar models. At the same time, it increases the lamination function between material particles and effectively improves the three-dimensional shape of the crushed material.

The equipment is superior to its peers
and the performance is unmatched

Product Advantages

The finished product has excellent particle size and reasonable grading

The compound cone crusher adopts an optimized crushing chamber design to ensure uniform discharge particle size and reasonable grading to meet the needs of high-standard aggregate production.

Hydraulic cavity clearing and overload protection to reduce downtime

Electric refrigeration oil lubrication, more stable operation

Grease seal for dust prevention, green and environmentally friendly

Compound Cone Crusher for sale in Peru

Raw material: Copper Ore
Model: CS315
Capacity: 350 T/H
Feeding size: ≤250 mm
Finished products: ≤30 mm (main target) / smaller sizes can be produced according to screening configuration

Free Quote

Product Parameters

Model	Movable Cone Diameter (mm)	Cavity Type	Feed Port Size(mm)		Discharging Port Size(mm)	Main Shaft Speed(r/min)	Motor Power(kw)	Capacity (t/h)	Overall Dimension (mm)
Model	Movable Cone Diameter (mm)	Cavity Type	Feeding Size(mm)	Opening Size(mm)	Discharging Port Size(mm)	Main Shaft Speed(r/min)	Motor Power(kw)	Capacity (t/h)	Overall Dimension (mm)
CS75	910	Fine Coarse	83 159	102 175	9-22 13-38	580	75	45-91 59-163	2821×1880×2164
CS110	1200	Fine Medium Coarse	127 156 178	131 156 191	9-31 13-38 19-51	485	110	63-188 100-200 141-308	2821×1974×2651
CS160	1295	Fine Medium Coarse	109 188 216	137 210 241	13-31 16-38 19-51	485	160	109-181 132-253 172-349	2800×2342×2668
CS220	1395	Fine Medium Coarse	155 188 230	173 198 245	19-45 22-50 25-65	485	220	180-285 215-330 230-570	3360×2650×3050
CS250	1650	Fine Medium Coarse	188 213 241	209 241 268	16-38 22-51 25-64	485	250	181-327 220-417 299-635	3911×2870×3771
CS315	2134	Fine Medium Coarse	253 303 334	278 334 369	19-38 25-51 31-64	435	315	281-726 608-998 789-1270	4631×3251×4732
