Trommel Screen
Discounts
Drum screen, also known as rotary drum screen, is a self-cleaning screening machine that separates materials by size. Compared to vibrating screens, drum screens can avoid clogging and achieve high yields even with dust and viscous materials. Drum screens are usually used in conjunction with mineral processing equipment, such as crushers and ball mills.


Adopting a small inclination installation structure (15-25 °) effectively prevents material blockage, reduces space occupation by 40%, and increases processing capacity by 30%.




| Model | Specification (mm) | Roller length(mm) | Speed (r/min) | Capacity (t/h) | Motor | Power(kw) |
|---|---|---|---|---|---|---|
| GS1410 | Φ1400/Φ1000 | 1500 | 20 | 10-20 | Y100L2-4 | 3 |
| GS1612 | Φ1600/Φ1200 | 1800 | 18 | 20-30 | Y112M-4 | 4 |
| GS2014 | Φ2000/Φ1400 | 2000 | 14 | 30-40 | Y132S-4 | 5.5 |
Do you need to know the product price? Model? Configuration plan? Output?
Please leave your correct information and we will reply to you within 24 hours.
