Product Introduction

Stationary Concrete Batching Plant is high-efficiency concrete production equipment specifically designed for large-scale construction projects, commercial concrete supply, and long-term infrastructure works. Thanks to its modular design and robust installation, it is suitable for various high-standard projects such as highway construction, bridges, high-rise buildings, hydroelectric power stations, and more.

Product Advantages

High Production Capacity

Output per single plant ranges from 25 m³/h to 240 m³/h, meeting the demands of projects of various scales.

Fully Automatic Control

Intelligent PLC control system with precise batching and weighing accuracy ≤1%, ensuring stable concrete strength.

Energy-Saving Design

Equipped with variable frequency drive (VFD) motors and optimized mixing blades, reducing energy consumption by 15-20%.

Environmental Protection

Fully enclosed structure with a dust removal system, compliant with CE / GOST environmental standards.

Fixed concrete batching plant for sale in Saudi Arabia

Raw material: Cement / Aggregates / Sand / Water / Admixtures
Model: ZJ50
Capacity: 50 m³/h
Feed material specification: Coarse aggregate ≤60 mm, fine aggregate ≤5 mm, cement silo capacity 80 tons × 1
Output quality:Fresh concrete slump 120±30 mm, compressive strength C20～C40 (customizable mix design)

Free Quote

Product Parameters

Model	ZJ25	ZJ35	ZJ50	ZJ60	ZJ75	ZJ90	ZJ120	ZJ180	ZJ240
Capacity	25 m³/h	35 m³/h	50 m³/h	60 m³/h	75 m³/h	90 m³/h	120 m³/h	180 m³/h	240 m³/h
Concrete Mixer	JS 500	JS750	JS1000	JS1000	JS1500	JS1500	JS2000	JS3000	JS4000
Mixer Capacity (Batch)	0.5 m³	0.75 m³	1 m³	1 m³	1.5 m³	1.5 m³	2 m³	3 m³	4 m³
Feeding Method	Skip Hoist	Skip Hoist	Skip Hoist	Belt Conveyor	Skip Hoist	Belt Conveyor	Belt Conveyor	Belt Conveyor	Belt Conveyor
Aggregate Batching Machine	PLD800	PLD1200	PLD1600	PLD1600	PLD2400	PLD2400	PLD3200	PLD4800	PLD6400
Number of Aggregate Bins	2/3/4	2/3/4	3/4	3/4/5	3/4	3/4/5	3/4/5	3/4/5	3/4/5
Max Aggregate Size	80/100 mm	80/100 mm	80/100 mm	80/100 mm	80/100 mm	80/100 mm	80/100 mm	80/100 mm	80/100 mm
Discharge Height	3.8 m	4.1 m	4.1 m	4.1 m	4.1 m	4.1 m	4.3 m	4.3 m	4.3 m
Aggregate Weighing Accuracy	±2%	±2%	±2%	±2%	±2%	±2%	±2%	±2%	±2%
Cement Weighing Accuracy	±1%	±1%	±1%	±1%	±1%	±1%	±1%	±1%	±1%
Water Weighing Accuracy	±1%	±1%	±1%	±1%	±1%	±1%	±1%	±1%	±1%
Additive Weighing Accuracy	±1%	±1%	±1%	±1%	±1%	±1%	±1%	±1%	±1%
Weight	10 ton	13.5 ton	18.5 ton	28 ton	25 ton	40 ton	65 ton	88 ton	98 ton
Total Installed Power	≤65 kW	≤75 kW	≤100 kW	≤110 kW	≤140 kW	≤160 kW	≤220 kW	≤290 kW	≤340 kW
