High Efficiency Powder Classifier-ZOOMJO

Product Introduction

The high-efficiency powder classifier adopts the organic combination of gravity centrifugal and cyclone eddy current multiple classification force fields, with high classification accuracy. The cage rotor is set to help the accumulated particles to be lifted up again, increase the classification capacity, and effectively reduce the fine powder content in the coarse powder.

Product Advantages

High powder selection efficiency

Using eddy current classification principle and dynamic rotor adjustment technology, the powder selection efficiency reaches 85%~92%

Easy installation

Modular pre-assembly design (including basic frame, transmission unit, cyclone), reducing 30% of working hours compared with traditional equipment

Adjustable fineness

Through hydraulic stepless speed regulation system and adjustable guide vanes, the fineness of the finished product is controlled online in real time

Classifier for sale in Turkey

Raw material: Cement Raw Meal
Model: XFD-1200
Capacity: 160 T/H
Feed Fineness: ≤25% R90μm
Product Fineness:Fine Product: ≤12% R45μm (Cement)
Coarse Reject: ≥80% R200μm

Free Quote

Product Parameters

Model	Output Per Unit Per Hour (t/h)		Product Fineness R0.08 (%)		Spindle Motor			Fan				Spindle Rotation Speed (rpm)
Model	Raw Material	Cement	Raw Material	Cement	Model	Power (kw)	Speed (rpm)	Model	Air Volume (m³/h)	Wind Pressure (pa)	Speed (rpm)	Spindle Rotation Speed (rpm)	Motor Model	Power (kw)
XFD400	12~16	16~22	8-10	≤(Surface area ≥32m²/kg)	YCTL200-4B	125-1250	7.5	SCF-12No8C	24216	2.18	1500	Y180M-4	22	190~380
XFD500	19~28	16~22			YCTL200-4B	125-1250	7.5	SCF-12No8C	30900	2.43	1600	Y200L1-4	30	190~380
XFD600	28~35	20~26			YCTL225-4A	132-1320	11	SCF-12No10C	37960	2.34	1200	Y225S-4	37	150~350
XFD700	33~46	26~35			YCTL225-4B	132-1320	15	SCF-12No12.5C	50520	2.84	1000	Y250M-4	55	150~350
XFD800	52~65	43~54			YCTL250-4A	132-1320	18.5	SCF-12No12.5C	71838	2.20	1000	Y280S-4	75	150~350
XFD900	70~86	50~68			YCTL250-4B	132-1320	22	SCF-12No16C	86006	2.21	720	Y355M1-6	90	150~350
XFD1000	110~130	85~105			YCTL315-4A	440-1340	37	SCF-12No16C	119332	2.26	800	Y355M1-8	132	140~350
XFD1100	140~160	115~135			YCTL315-4B	440-1340	55	SCF-12No16C	168000	2.70	960	Y355M1-6	160	100~300
XFD1200	215~240	160~180			YCTL355-4B	440-1340	75	SCF-12No18C	192000	2.70	960	Y355M3-6	200	100~300
